Corax was released just under a year ago, and we are seeing more customers deploying that to production. During a call with a customer, we noticed the following detail:

Let me explain what we are seeing here. The two indexes are the same, operating on the same set of documents. The only difference between those indexes is the indexing engine.

What is really amazing here is that Corax is able to index in 3:21 minutes what Lucene takes 17:15 minutes to index. In other words, Corax is more than 5 times faster than Lucene in a real world scenario.

And these news make me very happy.

RavenDB has a hidden feature, enabled by default and not something that you usually need to be aware of. It has built-in support for caching. Consider the following code:

async Task<Dictionary<string, int>> HowMuchWorkToDo(string userId)
{
    using var session = _documentStore.OpenAsyncSession();
    var results = await session.Query<Item>()
        .GroupBy(x =>new { x.Status, x.AssignedTo })
        .Where(g => g.Key.AssignedTo == userId && g.Key.Status != "Closed")
        .Select(g => new
        {
            Status = g.Key.Status,
            Count = g.Count()
        })
        .ToListAsync();


    return results.ToDictionary(x => x.Status, x => x.Count);
}

What happens if I call it twice with the same user? The first time, RavenDB will send the query to the server, where it will be evaluated and executed. The server will also send an ETag header with the response. The client will remember the response and its ETag in its own memory.

The next time this is called on the same user, the client will again send a request to the server. This time, however, it will also inform the server that it has a previous response to this query, with the specified ETag. The server, when realizing the client has a cached response, will do a (very cheap) check to see if the cached response matches the current state of the server. If so, it can inform the client (using 304 Not Modified) that it can use its cache.

In this way, we benefit twice:

• First, on the server side, we avoid the need to compute the actual query.
• Second, on the network side, we aren’t sending a full response back, just a very small notification to use the cached version.

You’ll note, however, that there is still an issue. We have to go to the server to check. That means that we still pay the network costs. So far, this feature is completely transparent to the user. It works behind the scenes to optimize server query costs and network bandwidth costs.

We have a full-blown article on caching in RavenDB if you care to know more details instead of just “it makes things work faster for me”.

Aggressive Caching in RavenDB

The next stage is to involve the user. Enter the AggressiveCache() feature (see the full documentation here), which allows the user to specify an additional aspect. Now, when the client has the value in the cache, it will skip going to the server entirely and serve the request directly from the cache.

What about cache invalidation? Instead of having the client check on each request if things have changed, we invert the process. The client asks the server to notify it when things change, and until it gets notice from the server, it can serve responses completely from the local cache.

I really love this feature, that was the Good part, now let’s talk about the other pieces:

There are only two hard things in Computer Science: cache invalidation and naming things.

-- Phil Karlton

The bad part of caching is that this introduces more complexity to the system. Consider a system with two clients that are using the same database. An update from one of them may show up at different times in each. Cache invalidation will not happen instantly, and it is possible to get into situations where the server fails to notify the client about the update, meaning that we didn’t clear the cache.

We have a good set of solutions around all of those, I think. But it is important to understand that the problem space itself is a problem.

In particular, let’s talk about dealing with the following query:

var emps = session.Query<Employee>()
    .Include(x => x.Department)
    .Where(x => x.Location.City == "London")
    .ToListAsync();

When an employee is changed on the server, it will send a notice to the client, which can evict the item from the cache, right? But what about when a department is changed?

For that matter, what happens if a new employee is added to London? How do we detect that we need to refresh this query?

There are solutions to those problems, but they are super complicated and have various failure modes that often require more computing power than actually running the query. For that reason, RavenDB uses a much simpler model. If the server notifies us about any change, we’ll mark the entire cache as suspect.

The next request will have to go to the server (again with an ETag, etc) to verify that the response hasn’t changed. Note that if the specific query results haven’t changed, we’ll get OK (304 Not Modified) from the server, and the client will use the cached response.

Conservatively aggressive approach

In other words, even when using aggressive caching, RavenDB still has to go to the server sometimes. What is the impact of this approach when you have a system under load?

We’ll still use aggressive caching, but you’ll see brief periods where we aren’t checking with the server (usually be able to cache for about a second or so), followed by queries to the server to check for any changes.

In most cases, this is what you want. We still benefit from the cache while reducing the number of remote calls by about 50%, and we don’t have to worry about missing updates. The downside is that, as application developers, we know that this particular document and query are independent, so we want to cache them until we get notice about that particular document being changed.

The default aggressive caching in RavenDB will not be of major help here, I’m afraid. But there are a few things you can do.

You can use Aggressive Caching in the NoTracking mode. In that mode, the client will not ask the server for notifications on changes, and will cache the responses in memory until they expire (clock expiration or size expiration only).

There is also a feature suggestion that calls for updating the aggressive cache in a background manner, I would love to hear more feedback on this proposal.

Another option is to take this feature higher than RavenDB directly, but still use its capabilities. Since we have a scenario where we know that we want to cache a specific set of documents and refresh the cache only when those documents are updated, let’s write it.

Here is the code:

public class RecordCache<T>
{
    private ConcurrentLru<string, T> _items =
        new(256, StringComparer.OrdinalIgnoreCase);
    private readonly IDocumentStore _documentStore;


    public RecordCache(IDocumentStore documentStore)
    {
        const BindingFlags Flags = BindingFlags.Instance |
            BindingFlags.NonPublic | BindingFlags.Public;
        var violation = typeof(T).GetFields(Flags)
            .FirstOrDefault(f => f.IsInitOnly is false);
        if (violation != null)
        {
            throw new InvalidOperationException(
                "You should cache *only* immutable records, but got: " +
                typeof(T).FullName + " with " + violation.Name +
                " which is not read only!");
        }


        var changes = documentStore.Changes();
        changes.ConnectionStatusChanged += (_, args) =>
        {
            _items = new(256, StringComparer.OrdinalIgnoreCase);
        };
        changes.ForDocumentsInCollection<T>()
            .Subscribe(e =>
            {
                _items.TryRemove(e.Id, out _);
            })
            ;
        _documentStore = documentStore;
    }


    public ValueTask<T> Get(string id)
    {
        if (_items.TryGetValue(id, out var result))
        {
            return ValueTask.FromResult(result);
        }
        return new ValueTask<T>(GetFromServer(id));


    }


    private async Task<T> GetFromServer(string id)
    {
        using var session = _documentStore.OpenAsyncSession();
        var item = await session.LoadAsync<T>(id);
        _items.Set(id, item);
        return item;
    }
}

There are a few things to note about this code. We are holding live instances, so we ensure that the values we keep are immutable records. Otherwise, we may hand the same instance to two threads which can be… fun.

Note that document IDs in RavenDB are case insensitive, so we pass the right string comparer.

Finally,  the magic happens in the constructor. We register for two important events. Whenever the connection status of the Changes() connection is modified, we clear the cache. This handles any lost updates scenarios that occurred while we were disconnected.

In practice, the subscription to events on that particular collection is where we ensure that after the server notification, we can evict the document from the cache so that the next request will load a fresh version.

Caching + Distributed Systems = 🤯🤯🤯

I’m afraid this isn’t an easy topic once you dive into the specifics and constraints we operate under. As I mentioned, I would love your feedback on the background cache refresh feature, or maybe you have better insight into other ways to address the topic.

RavenDB is a pretty old codebase, hitting 15+ years in production recently. In order to keep it alive & well, we make sure to follow the rule of always leaving the code in a better shape than we found it.

Today’s tale is about the StreamBitArray class, deep in the guts of Voron, RavenDB’s storage engine. The class itself isn’t really that interesting, it is just an implementation of a Bit Array that we have for a bitmap. We wrote it (based on Mono’s code, it looks like) very early in the history of RavenDB and have never really touched it since.

The last time anyone touched it was 5 years ago (fixing the namespace), 7 years ago we created an issue from a TODO comment, etc. Most of the code dates back to 2013, actually. And even then it was moved from a different branch, so we lost the really old history.

To be clear, that class did a full tour of duty. For over a decade, it has served us very well. We never found a reason to change it, never got a trace of it in the profiler, etc. As we chip away at various hurdles inside RavenDB, I ran into this class and really looked at it with modern sensibilities. I think that this makes a great test case for code refactoring from the old style to our modern one.

Here is what the class looks like:

Already, we can see several things that really bug me. That class is only used in one context, to manage the free pages bitmap for Voron. That means we create it whenever Voron frees a page. That can happen a lot, as you might imagine.

A single bitmap here covers 2048 pages, so when we create an instance of this class we also allocate an array with 64 ints. In other words, we need to allocate 312 bytes for each page we free. That isn’t fun, and it actually gets worse. Here is a typical example of using this class:

using (freeSpaceTree.Read(section, out Slice result))
{
    sba = !result.HasValue ?
              new StreamBitArray() :
              new StreamBitArray(result.CreateReader());
}
sba.Set((int)(pageNumber % NumberOfPagesInSection), true);
using (sba.ToSlice(tx.Allocator, out Slice val))
    freeSpaceTree.Add(section, val);

And inside the ToSlice() call, we have:

public ByteStringContext.InternalScope ToSlice(ByteStringContext context,
ByteStringType type, out Slice str)
{
    var buffer = ToBuffer();
    var scope = context.From(buffer, 0, buffer.Length,
type, out ByteString byteString);
    str = new Slice(byteString);
    return scope;
}


private unsafe byte[] ToBuffer()
{
    var tmpBuffer = new byte[(_inner.Length + 1)*sizeof (int)];
    unsafe
    {
        fixed (int* src = _inner)
        fixed (byte* dest = tmpBuffer)
        {
            *(int*) dest = SetCount;
            Memory.Copy(dest + sizeof (int), (byte*) src,
                                             tmpBuffer.Length - 1);
        }
    }
    return tmpBuffer;
}

In other words, ToSlice() calls ToBuffer(), which allocates an array of bytes (288 bytes are allocated here), copies the data from the inner buffer to a new one (using fixed on the two arrays, which is a performance issue all in itself) and then calls a method to do the actual copy. Then in ToSlice() itself we allocate it again in native memory, which we then write to Voron, and then discard the whole thing.

In short, somehow it turns out that freeing a page in Voron costs us ~1KB of memory allocations. That sucks, I have to say. And the only reasoning I have for this code is that it is old.

Here is the constructor for this class as well:

public StreamBitArray(ValueReader reader)
{
    SetCount = reader.ReadLittleEndianInt32();
    unsafe
    {
        fixed (int* i = _inner)
        {
            int read = reader.Read((byte*)i, _inner.Length * sizeof(int));
            if (read < _inner.Length * sizeof(int))
                throw new EndOfStreamException();
        }
    }
}

This accepts a reader to a piece of memory and does a bunch of things. It calls a few methods, uses fixed on the array, etc., all to get the data from the reader to the class. That is horribly inefficient.

Let’s write it from scratch and see what we can do. The first thing to notice is that this is a very short-lived class, it is only used inside methods and never held for long. This usage pattern tells me that it is a good candidate to be made into a struct, and as long as we do that, we might as well fix the allocation of the array as well.

Note that I have a hard constraint, I cannot change the structure of the data on disk for backward compatibility reasons. So only in-memory changes are allowed.

Here is my first attempt at refactoring the code:

public unsafe struct StreamBitArray
{
    private fixed uint _inner[64];
    public int SetCount;


     public StreamBitArray()
     {
         SetCount = 0;
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[0]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[8]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[16]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[24]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[32]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[40]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[48]);
         Vector256<uint>.Zero.StoreUnsafe(ref _inner[56]);
     }


     public StreamBitArray(byte* ptr)
     {
         var ints = (uint*)ptr;
         SetCount = (int)*ints;
         var a = Vector256.LoadUnsafe(ref ints[1]);
         var b = Vector256.LoadUnsafe(ref ints[9]);
         var c = Vector256.LoadUnsafe(ref ints[17]);
         var d = Vector256.LoadUnsafe(ref ints[25]);
         var e = Vector256.LoadUnsafe(ref ints[33]);
         var f = Vector256.LoadUnsafe(ref ints[41]);
         var g = Vector256.LoadUnsafe(ref ints[49]);
         var h = Vector256.LoadUnsafe(ref ints[57]);


         a.StoreUnsafe(ref _inner[0]);
         b.StoreUnsafe(ref _inner[8]);
         c.StoreUnsafe(ref _inner[16]);
         d.StoreUnsafe(ref _inner[24]);
         e.StoreUnsafe(ref _inner[32]);
         f.StoreUnsafe(ref _inner[40]);
         g.StoreUnsafe(ref _inner[48]);
         h.StoreUnsafe(ref _inner[56]);
     }
}

That looks like a lot of code, but let’s see what changes I brought to bear here.

• Using a struct instead of a class saves us an allocation.
• Using a fixed array means that we don’t have a separate allocation for the buffer.
• Using [SkipLocalsInit] means that we ask the JIT not to zero the struct. We do that directly in the default constructor.
• We are loading the data from the ptr in the second constructor directly.

The fact that this is a struct and using a fixed array means that we can create a new instance of this without any allocations, we just need 260 bytes of stack space (the 288 we previously allocated also included object headers).

Let’s look at the actual machine code that these two constructors generate. Looking at the default constructor, we have:

StreamBitArray..ctor()
    L0000: push ebp
    L0001: mov ebp, esp
    L0003: vzeroupper
    L0006: xor eax, eax
    L0008: mov [ecx+0x100], eax
    L000e: vxorps ymm0, ymm0, ymm0
    L0012: vmovups [ecx], ymm0
    L0016: vmovups [ecx+0x20], ymm0
    L001b: vmovups [ecx+0x40], ymm0
    L0020: vmovups [ecx+0x60], ymm0
    L0025: vmovups [ecx+0x80], ymm0
    L002d: vmovups [ecx+0xa0], ymm0
    L0035: vmovups [ecx+0xc0], ymm0
    L003d: vmovups [ecx+0xe0], ymm0
    L0045: vzeroupper
    L0048: pop ebp
    L0049: ret

There is the function prolog and epilog, but the code of this method uses 4 256-bit instructions to zero the buffer. If we were to let the JIT handle this, it would use 128-bit instructions and a loop to do it. In this case, our way is better, because we know more than the JIT.

As for the constructor accepting an external pointer, here is what this translates into:

StreamBitArray..ctor(Byte*)
    L0000: push ebp
    L0001: mov ebp, esp
    L0003: vzeroupper
    L0006: mov eax, [edx]
    L0008: mov [ecx+0x100], eax
    L000e: vmovups ymm0, [edx+4]
    L0013: vmovups ymm1, [edx+0x24]
    L0018: vmovups ymm2, [edx+0x44]
    L001d: vmovups ymm3, [edx+0x64]
    L0022: vmovups ymm4, [edx+0x84]
    L002a: vmovups ymm5, [edx+0xa4]
    L0032: vmovups ymm6, [edx+0xc4]
    L003a: vmovups ymm7, [edx+0xe4]
    L0042: vmovups [ecx], ymm0
    L0046: vmovups [ecx+0x20], ymm1
    L004b: vmovups [ecx+0x40], ymm2
    L0050: vmovups [ecx+0x60], ymm3
    L0055: vmovups [ecx+0x80], ymm4
    L005d: vmovups [ecx+0xa0], ymm5
    L0065: vmovups [ecx+0xc0], ymm6
    L006d: vmovups [ecx+0xe0], ymm7
    L0075: vzeroupper
    L0078: pop ebp
    L0079: ret

This code is exciting to me because we are also allowing instruction-level parallelism. We effectively allow the CPU to execute all the operations of reading and writing in parallel.

Next on the chopping block is this method:

public int FirstSetBit()
{
    for (int i = 0; i < _inner.Length; i++)
    {
        if (_inner[i] == 0)
            continue;
        return i << 5 | HighestBitSet(_inner[i]);
    }
    return -1;
}


private static int HighestBitSet(int v)
{


    v |= v >> 1; // first round down to one less than a power of 2
    v |= v >> 2;
    v |= v >> 4;
    v |= v >> 8;
    v |= v >> 16;


    return MultiplyDeBruijnBitPosition[(uint)(v * 0x07C4ACDDU) >> 27];
}

We are using vector instructions to scan 8 ints at a time, trying to find the first one that is set. Then we find the right int and locate the first set bit there. Here is what the assembly looks like:

StreamBitArray.FirstSetBit()
    L0000: push ebp
    L0001: mov ebp, esp
    L0003: vzeroupper
    L0006: xor edx, edx
    L0008: cmp [ecx], cl
    L000a: vmovups ymm0, [ecx+edx*4]
    L000f: vxorps ymm1, ymm1, ymm1
    L0013: vpcmpud k1, ymm0, ymm1, 6
    L001a: vpmovm2d ymm0, k1
    L0020: vptest ymm0, ymm0
    L0025: jne short L0039
    L0027: add edx, 8
    L002a: cmp edx, 0x40
    L002d: jl short L000a
    L002f: mov eax, 0xffffffff
    L0034: vzeroupper
    L0037: pop ebp
    L0038: ret
    L0039: vmovmskps eax, ymm0
    L003d: tzcnt eax, eax
    L0041: add eax, edx
    L0043: xor edx, edx
    L0045: tzcnt edx, [ecx+eax*4]
    L004a: shl eax, 5
    L004d: add eax, edx
    L004f: vzeroupper
    L0052: pop ebp
    L0053: ret

In short, the code is simpler, shorter, and more explicit about what it is doing. The machine code that is running there is much tighter. And I don’t have allocations galore.

This particular optimization isn’t about showing better numbers in a specific scenario that I can point to. I don’t think we ever delete enough pages to actually see this in a profiler output in such an obvious way. The goal is to reduce allocations and give the GC less work to do, which has a global impact on the performance of the system.

During a performance evaluation internally, we ran into a strange situation. Our bulk insert performance using the node.js API was significantly worse than the performance of other clients. In particular, when we compared that to the C# version, we saw that the numbers were significantly worse than expected.

To be fair, this comparison is made between our C# client, which has been through the wringer in terms of optimization and attention to performance, and the Node.js client. The focus of the Node.js client was on correctness and usability.

It isn’t fair to expect the same performance from Node.js and C#, after all. However, that difference in performance was annoying enough to make us take a deeper look into what was going on.

Here is the relevant code:

const store = new DocumentStore('http://localhost:8080', 'bulk');


store.initialize();


const bulk = store.bulkInsert();
for (let i = 0; i < 100_000_000; i++) {
    await bulk.store(new User('user' + i));
}
await bulk.finish();

As you can see, the Node.js numbers are respectable. Running at a rate of over 85,000 writes per second is nothing to sneeze at.

But I also ran the exact same test with the C# client, and I got annoyed. The C# client was able to hit close to 100,000 more writes per second than the Node.js client. And in both cases, the actual limit was on the client side, not on the server side.

For fun, I ran a few clients and hit 250,000 writes/second without really doing much. The last time we properly tested ingest performance for RavenDB we achieved 150,000 writes/second. So it certainly looks like we are performing significantly better.

Going back to the Node.js version, I wanted to know what exactly was the problem that we had there. Why are we so much slower than the C# version? It’s possible that this is just the limits of the node.js platform, but you gotta check to know.

Node.js has an --inspect flag that you can use, and Chrome has a built-in profiler (chrome://inspect) that can plug into that. Using the DevTools, you can get a performance profile of a Node.js process.

I did just that and go the following numbers:

That is… curious. Really curious, isn’t it?

Basically, none of my code appears here at all, most of the time is spent dealing with the async machinery. If you look at the code above, you can see that we are issuing an await for each document stored.

The idea with bulk insert is that under the covers, we split the writing to an in-memory buffer and the flushing of the buffer to the network. In the vast majority of cases, we’ll not do any async operations in the store() call. If the buffer is full, we’ll need to flush it to the network, and that may force us to do an actual await operation. In Node.js, awaiting an async function that doesn’t actually perform any async operation appears to be super expensive.

We threw around a bunch of ideas on how to resolve this issue. The problem is that Node.js has no equivalent to C#’s ValueTask. We also have a lot of existing code out there in the field that we must remain compatible with.

Our solution to this dilemma was to add another function that you can call, like so:

for (let i = 0; i < 100_000_000; i++) {
    const user = new User('user' + i);
    const id = "users/" + i;
    if (bulk.tryStoreSync(user, id) == false) {
        await bulk.store(user, id);
    }
}

The idea is that if you call tryStoreSync() we’ll try to do everything in memory, but it may not be possible (e.g. if we need to flush the buffer). In that case, you’ll need to call the async function store() explicitly.

Given that the usual reason for using the dedicated API for bulk insert is performance, this looks like a reasonable thing to ask. Especially when you can see the actual performance results. We are talking about over 55%(!!!) improvement in the performance of bulk insert.

It gets even better. That was just the mechanical fix to avoid generating a promise per operation. While we are addressing this performance issue, there are a few other low-hanging fruits that could improve the bulk insert performance in Node.js.

For example, it turns out that we pay a hefty cost to generate the metadata for all those documents (runtime reflection cost, mostly). We can generate it once and be done with it, like so:

const bulk = store.bulkInsert();
const metadata = {
    "@collection": "Users",
    "Raven-Node-Type": "User"
};
for (let i = 0; i < 100_000_000; i++) {
    const user = new User('user' + i);
    const id = "users/" + i;
    if (bulk.tryStoreSync(user, id, metadata) == false) {
        await bulk.store(user, id, metadata);
    }
}
await bulk.finish();

And this code in particular gives us:

That is basically near enough to the C#’s speed that I don’t think we need to pay more attention to performance. Overall, that was time very well spent in making things go fast.

A customer called us about some pretty weird-looking numbers in their system:

You’ll note that the total number of entries in the index across all the nodes does not match. Notice that node C has 1 less entry than the rest of the system.

At the same time, all the indicators are green. As far as the administrator can tell, there is no issue, except for the number discrepancy. Why is it behaving in this manner?

Well, let’s zoom out a bit. What are we actually looking at here? We are looking at the state of a particular index in a single database within a cluster of machines. When examining the index, there is no apparent problem. Indexing is running properly, after all.

The actual problem was a replication issue, which prevented replication from proceeding to the third node. When looking at the index status, you can only see that the entry count is different.

When we zoom out and look at the state of the cluster, we can see this:

There are a few things that I want to point out in this scenario. The problem here is a pretty nasty one. All nodes are alive and well, they are communicating with each other, and any simple health check you run will give good results.

However, there is a problem that prevents replication from properly flowing to node C. The actual details aren’t relevant (a bug that we fixed, to tell the complete story). The most important aspect is how RavenDB behaves in such a scenario.

The cluster detected this as a problem, marked the node as problematic, and raised the appropriate alerts. As a result of this, clients would automatically be turned away from node C and use only the healthy nodes.

From the customer’s perspective, the issue was never user-visible since the cluster isolated the problematic node. I had a hand in the design of this, and I wrote some of the relevant code. And I’m still looking at these screenshots with a big sense of accomplishment.

This stuff isn’t easy or simple. But to an outside observer, the problem started from: why am I looking at funny numbers in the index state in the admin panel? And not at: why am I serving the wrong data to my users.

The design of RavenDB is inherently paranoid. We go to a lot of trouble to ensure that even if you run into problems, even if you encounter outright bugs (as in this case), the system as a whole would know how to deal with them and either recover or work around the issue.

As you can see, live in production, it actually works and does the Right Thing for you. Thus, I can end this post by saying that this behavior makes me truly happy.

We recently got a support request from a user in which they had the following issue:

We have an index that is using way too much disk space. We don’t need to search the entire dataset, just the most recent documents. Can we do something like this?

from d in docs.Events
where d.CreationDate >= DateTime.UtcNow.AddMonths(-3)
select new { d.CreationDate, d.Content };

The idea is that only documents from the past 3 months would be indexed, while older documents would be purged from the index but still retained.

The actual problem is that this is a full-text search index, and the actual data size required to perform a full-text search across the entire dataset is higher than just storing the documents (which can be easily compressed).

This is a great example of an XY problem. The request was to allow access to the current date during the indexing process so the index could filter out old documents. However, that is actually something that we explicitly prevent. The problem is that the current date isn’t really meaningful when we talk about indexing. The indexing time isn’t really relevant for filtering or operations, since it has no association with the actual data.

The date of a document and the time it was indexed are completely unrelated. I might update a document (and thus re-index it) whose CreationDate is far in the past. That would filter it out from the index. However, if we didn’t update the document, it would be retained indefinitely, since the filtering occurs only at indexing time.

Going back to the XY problem, what is the user trying to solve? They don’t want to index all data, but they do want to retain it forever. So how can we achieve this with RavenDB?

Data Archiving in RavenDB

One of the things we aim to do with RavenDB is ensure that we have a good fit for most common scenarios, and archiving is certainly one of them. In RavenDB 6.0 we added explicit support for Data Archiving.

When you save a document, all you need to do is add a metadata element: @archive-at and you are set. For example, take a look at the following document:

{
    "Name": "Wilman Kal",
    "Phone": "90-224 8888",
    "@metadata": {
        "@archive-at": "2024-11-01T12:00:00.000Z",
        "@collection": "Companies",
     }
}

This document is set to be archived on Nov 1st, 2024. What does that mean?

From that day on, RavenDB will automatically mark it as an archived document, meaning it will be stored in a compressed format and excluded from indexing by default.

In fact, this exact scenario is detailed in the documentation.

You can decide (on a per-index basis) whether to include archived documents in the index. This gives you a very high level of flexibility without requiring much manual effort.

In short, for this scenario, you can simply tell RavenDB when to archive the document and let RavenDB handle the rest. RavenDB will do the right thing for you.

In my previous post, I explained what we are trying to do. Create a way to carry a dictionary between transactions in RavenDB, allowing one write transaction to modify it while all other read transactions only observe the state of the dictionary as it was at the publication time.

I want to show a couple of ways I tried solving this problem using the built-in tools in the Base Class Library. Here is roughly what I’m trying to do:

IEnumerable<object> SingleDictionary()
{
    var dic = new Dictionary<long, object>();
    var random = new Random(932);
    var v = new object();
    // number of transactions
    for (var txCount = 0; txCount < 1000; txCount++)
    {
        // operations in transaction
        for (int opCount = 0; opCount < 10_000; opCount++)
        {
            dic[random.NextInt64(0, 1024 * 1024 * 1024)] = v;
        }
        yield return dic;// publish the dictionary
    }
}

As you can see, we are running a thousand transactions, each of which performs 10,000 operations. We “publish” the state of the transaction after each time.

This is just to set up a baseline for what I’m trying to do. I’m focusing solely on this one aspect of the table that is published. Note that I cannot actually use this particular code. The issue is that the dictionary is both mutable and shared (across threads), I cannot do that.

The easiest way to go about this is to just clone the dictionary. Here is what this would look like:

IEnumerable<object> ClonedDictionary()
{
    var dic = new Dictionary<long, object>();
    var random = new Random(932);
    var v = new object();
    // number of transactions
    for (var txCount = 0; txCount < 1000; txCount++)
    {
        // operations in transaction
        for (int opCount = 0; opCount < 10_000; opCount++)
        {
            dic[random.NextInt64(0, 1024 * 1024 * 1024)] = v;
        }
       // publish the dictionary
        yield return new Dictionary<long, object>(dic);
    }
}

This is basically the same code, but when I publish the dictionary, I’m going to create a new instance (which will be read-only). This is exactly what I want: to have a cloned, read-only copy that the read transactions can use while I get to keep on modifying the write copy.

The downside of this approach is twofold. First, there are a lot of allocations because of this, and the more items in the table, the more expensive it is to copy.

I can try using the ImmutableDictionary in the Base Class Library, however. Here is what this would look like:

IEnumerable<object> ClonedImmutableDictionary()
{
    var dic = ImmutableDictionary.Create<long, object>();


    var random = new Random(932);
    var v = new object();
    // number of transactions
    for (var txCount = 0; txCount < 1000; txCount++)
    {
        // operations in transaction
        for (int opCount = 0; opCount < 10_000; opCount++)
        {
            dic = dic.Add(random.NextInt64(0, 1024 * 1024 * 1024), v);
        }
        // publish the dictionary
        yield return dic;
    }
}

The benefit here is that the act of publishing is effectively a no-op. Just send the immutable value out to the world. The downside of using immutable dictionaries is that each operation involves an allocation, and the actual underlying implementation is far less efficient as a hash table than the regular dictionary.

I can try to optimize this a bit by using the builder pattern, as shown here:

IEnumerable<object> BuilderImmutableDictionary()
{
    var builder = ImmutableDictionary.CreateBuilder<long, object>();


    var random = new Random(932);
    var v = new object(); ;
    // number of transactions
    for (var txCount = 0; txCount < 1000; txCount++)
    {
        // operations in transaction
        for (int opCount = 0; opCount < 10_000; opCount++)
        {
            builder[random.NextInt64(0, 1024 * 1024 * 1024)] = v;
        }
        // publish the dictionary
        yield return builder.ToImmutable();
    }
}

Now we only pay the immutable cost one per transaction, right? However, the underlying implementation is still an AVL tree, not a proper hash table. This means that not only is it more expensive for publishing the state, but we are now slower for reads as well. That is not something that we want.

The BCL recently introduced a FrozenDictionary, which is meant to be super efficient for a really common case of dictionaries that are accessed a lot but rarely written to. I delved into its implementation and was impressed by the amount of work invested into ensuring that this will be really fast.

Let’s see how that would look like for our scenario, shall we?

IEnumerable<object> FrozenDictionary()
{
    var dic = new Dictionary<long, object>();
    var random = new Random(932);
    var v = new object();
    // number of transactions
    for (var txCount = 0; txCount < 1000; txCount++)
    {
        // operations in transaction
        for (int opCount = 0; opCount < 10_000; opCount++)
        {
            dic[random.NextInt64(0, 1024 * 1024 * 1024)] = v;
        }
        // publish the dictionary
        yield return dic.ToFrozenDictionary();
    }
}

The good thing is that we are using a standard dictionary on the write side and publishing it once per transaction. The downside is that we need to pay a cost to create the frozen dictionary that is proportional to the number of items in the dictionary. That can get expensive fast.

After seeing all of those options, let’s check the numbers. The full code is in this gist.

I executed all of those using Benchmark.NET, let’s see the results.

Note that the difference in speed is absolutely staggering. The SingleDictionaryBench is a bad example. It is just filling a dictionary directly, with no additional cost. The cost for the BuilderImmutableDictionaryBench is more reasonable, given what it has to do.

Just looking at the benchmark result isn’t sufficient. I implemented every one of those options in RavenDB and ran them under a profiler. The results are quite interesting.

Here is the version I started with, using a frozen dictionary. That is the right data structure for what I want. I have one thread that is mutating data, then publish the frozen results for others to use.

However, take a look at the profiler results! Don’t focus on the duration values, look at the percentage of time spent creating the frozen dictionary. That is 60%(!) of the total transaction time. That is… an absolutely insane number.

Note that it is clear that the frozen dictionary isn’t suitable for our needs here. The ratio between reading and writing isn’t sufficient to justify the cost. One of the benefits of FrozenDictionary is that it is more expensive to create than normal since it is trying hard to optimize for reading performance.

What about the ImmutableDictionary? Well, that is a complete non-starter. It is taking close to 90%(!!) of the total transaction runtime. I know that I called the frozen numbers insane, I should have chosen something else, because now I have no words to describe this.

Remember that one problem here is that we cannot just use the regular dictionary or a concurrent dictionary. We need to have a fixed state of the dictionary when we publish it. What if we use a normal dictionary, cloned?

This is far better, at about 40%, instead of 60% or 90%.

You have to understand, better doesn’t mean good. Spending those numbers on just publishing the state of the transaction is beyond ridiculous.

We need to find another way to do this. Remember where we started? The PageTable in RavenDB that currently handles this is really complex.

I looked into my records and found this blog post from over a decade ago, discussing this exact problem. It certainly looks like this complexity is at least semi-justified.

I still want to be able to fix this… but it won’t be as easy as reaching out to a built-in type in the BCL, it seems.

We recently published an article on Getting started with GraphQL and RavenDB, it will walk you through setting up Hot Chocolate to create a RavenDB-based GraphQL endpoint in your system.

Here is what this looks like:
